DETAILS
3-in-1 kits offer three complete pushbutton switches with shields in one package. Includes three snap-in messages and three activation choices (momentary, turn-to-reset, key-to-reset) per button. Kits for the pushbutton switches are available in blue, green, or yellow.
Key Features
DESIGN
DESIGN
- Unique, curved design helps protect against accidental activation.
- Optional illumination (red, green, white) can be used as a status light, indicating activation.
CONSTRUCTION
CONSTRUCTION
- Station housing molded of tough polycarbonate.
- Stainless steel backplate.
- UL/cUL Listed S7255, UL2017, CSA c22.2 No. 205.
- Buttons are ADA Compliant.
INSTALLATION
INSTALLATION
- 5VA flammability rating on backplate and spacer.
- Typical working properties of polycarbonate are -40° to 250°F (-40° to 121°C).
ELECTRONICS
ELECTRONICS
- 2 Form C contacts rated at 10A, ½ HP, 125/250 VAC, 6A, 30V.
OPTIONS
OPTIONS
- Available in three colors.
- Change button activation on site: Key-to-Reset, Turn-to-Reset, Momentary (default).
- Snap-in message choices: EMERGENCY EXIT, Blank, EXIT.
- Optional illumination (red, green, white).
OTHER FEATURES
OTHER FEATURES
- Multipurpose push button switches cover a wide range of applications both indoors and outdoors.
- Included Stopper® Station Shield protects from damage and accidental activation.
- Three year guarantee against breakage of polycarbonate in normal use (one year on electro mechanical and electronic components).
